AR-ONE Receptor 10kHz ~ 3.3GHz

AOR

  • AR-ONE Receptor 10kHz ~ 3.3GHz
Disponibilidade: Este produto não está disponível para venda em nossa loja virtual. Por favor, solicite uma cotação pelo e-mail sac@radiohaus.com.br



 Em breve traducão em Português (BR).



The AR-ONE giver you total command of frequencies, modes, tuning steps and more. It is possible to tune in increments of one Hz.

Surveillance operations are enhanced. Monitoring multiple frequencies is easier and faster. Computer control giver you maximum flexibility and unleashes the many features found in this advanced technology receiver.

The AR-ONE is the right choice for the new world we now monitor.

• Super wide coverage 10 kHz ~ 3.3 GHz

• 1000 memory channels

• 10 VFOs

• Monitor AM, NFM, WFM, USB, LSB, CW, Data

• Ultra-stable reference frequency oscillator

• Two RS-232C ports plus control head port

• Control up to 99 AR-ONE Units with one PC

• Triple conversion super heterodyne front end

• Antenna input level readout

• Adjustable BFO

• High intercept

• Multi IF signal output (10.7 MHz or 455 kHz)

• Excellent sensitivity

The AR-ONE is designed for use by the monitoring professional. The AR-ONE is so advanced, you will be thinking of new applications for its powerful capabilities.

  Em breve traducão em Português (BR).


Configuration

Conversor tirplo de sup

cobertura de frequência



10 kHz – 3.3 GHz

Modos de Recepção



AM, NFM, WFM, USB, LSB, CW, DATA

Seletividade

B/W                      -6Db                      -60dB

0.5kHz

0.5kHz>

<2kHz

3kHz

3kHz>

<6kHz

9kHz

9kHz>

<30kHz

15kHz

15kHz>

<40kHz

30kHz

30kHz>

<70kHz

110kHz

110kHz>

<450kHz

220kHz

220kHz>

<600kHz

300kHz

300kHz>

<900kHz



Sensibilidade espúria

60dB>

Seletividade adjacente

55dB>

Alcance Dinâmico



90dB>

Emissão de espúrios indesejado

< -57dBm

IP3

_2dBm > (-1dBm > above 2.5GHz)

estabilidade de frequência



± 0.1 ppm (-10 ~ 50C)

Sensibilidade



(AM mode -10dB S/N, NFM mode -12dB SINAD, CW/SSB mode -10dB S/N)

10 ~ 40 kHz:

CW 22.3 uV

40 ~ 100 kHz:

AM -4 uV, CW -1.5 uV

100 kHz ~ 40 MHz:

AM 2.5 uV, 2 ~ 40 MHz: AM -1.5 uV, SSB/CW – 0.7 uV, NFM -0.89 uV

40 MHz ~ 1 GHz:

AM -0.89 uV, SSB/CW

 -0.4 uV, NFM -0.5uV, WFM -1.5 uV

1 GHz ~ 2.5 GHz:

AM -0.7 uV, SSB/CW

-0.32 uV, NFM -0.4 uV, WFM -1.5 uV

2.5 GHz ~ 3.3 GHz:

AM -0.9 uV, SSB/CW

-0.32 uV, NFM -0.5 uV, WFM -1.5 uV

IF Frequências

1st IF: 754 MHz/265 MHz

2nd IF: 10.7 MHz

3rd IF: 455 kHz

Passos de sintonia



1 Hz to 1 MHz (1 Hz incremental)

Distorção

20dB > (< 10%)

Saída de Aúdio



1.5W (8 Ohm) @ 10% distortion

Requerimento de força



13.5V DC, < 2 amp. (@ 1W audio output)

Impêdancia da Antena



50 Ohm N-TYPE

Saída de IF

10.7 MHz or 455 kHz @ -20dBm

entrada padrão de frequência externa



10 MHz (0dBm ± 3dB)

Interface de controle

RS-232C up to 38400bps

Temperatura de operação

-10 to 50 degrees Celsius

Dimensões

157(W) x 58(H) x 270(D) mm excluding projections

Peso



Approx. 2.2Kg

larguras de banda de filtro nominais



0.5kHz, 3kHz, 6kHz, 9kHz, 15kHz, 30kHz, 110kHz & 220kHz, 300kHz.

Canal de Memórias



1000 (10 banks)

Digitalização / taxa de Pesquisa



25 steps per second.
